Sewage Treatment Plant (STP) - My Water Ltd
My Water Ltd utilizes advanced technology to treat domestic, commercial, and industrial wastewater (sewage), making it eco-friendly and reusable. Our STP systems are highly cost-effective, space-saving, and maintain international quality standards.
1. Process Description
A standard STP primarily operates in 4 key stages:
Preliminary Treatment: In this stage, large debris (plastic, cloth, stones) is separated through screening, and sand or heavy particles are removed in the grit chamber.
Primary Treatment: Water is kept still in a sedimentation tank so that heavy waste settles at the bottom (Sludge) and oil or grease floats to the top.
Secondary (Biological) Treatment: This is the heart of the plant. Using MBBR or ASP technology, aerobic bacteria are used to break down and destroy organic matter in the water.
Tertiary Treatment: Finally, the water is made completely clear and germ-free using sand filters, carbon filters, and chlorination or UV systems.
2. Technical Specification
My Water Ltd provides customized plants based on customer requirements and water volume. Below is a standard specification:
| Parameter | Description |
| Capacity | 5 KLD to 1000+ KLD (As per requirement) |
| Technology | MBBR (Moving Bed Biofilm Reactor) / MBR / SBR |
| Material of Construction | RCC (Civil Structure) or MS/FRP (Package Plant) |
| Feed Pump | Non-clogging centrifugal pump |
| Aeration System | Twin Lobe Air Blowers with Fine Bubble Diffusers |
| Filtration | Pressure Sand Filter (PSF) & Activated Carbon Filter (ACF) |
| Disinfection | Chlorine Dosing / UV Sterilizer |
| Automation | Semi-automatic / Fully Automatic (PLC Based) |
Description
3. Benefits of Using My Water Ltd's STP
Water Savings: Treated water can be reused for gardening, toilet flushing, or fire-fighting.
Environmental Protection: Prevents environmental pollution by ensuring wastewater is not discharged directly into drains.
Legal Compliance: Helps in adhering to the guidelines and policies of the DoE (Department of Environment).
Durability: The use of high-quality pumps and filter media ensures long-term, uninterrupted service.
